SPO12-TA Two Post Lift 12000lb Capacity

Rotary / Model SPO12-TA / Please Call for Lead Time

Back to catalog Ask support
SPO12-TA Two Post Lift 12000lb Capacity

12,000lb Two Post Symmetrical - Rotary Lift - Automotive Lifts



SPO12-TA
Surface Mounted, Frame Contact Lift. Overhead Equalization System, Arm Restraints -- All Arms, Electric- Hydraulic Operation. Comes standard with (4) FJ6143, (2) FJ6144 and (1) FJ6158 Adapters.
Low Ceiling Application. Total Height 13' 8"

Single piece "double S" column, front and rear three stage arms, stackable thread-up truck adapters.Customizable features include low ceiling or extended height settings.Choose to supercharge your lift with Shockwave.


Specification
  • Capacity 12,000 lbs.
  • Rise 80 1/4"
  • Overall Height 13' 8"
  • Required Ceiling Height 14'
  • Overall Width 11' 5 5/8"
  • Drive-Thru Width 8' 6 3/8"
  • Front Arm Min/Max 27 1/2"-59"
  • Rear Arm Min/Max 27 1/2"-59"
  • Min. Adapter Height 4 3/4"
  • Motor 2 HP
  • Voltage 208v-230v
  • Time of Full Rise/Decent 60 secs./40 secs.
  • Min. Bay Size 12'x26'
