Rotary SMO123 Parts Diagram

Diagrams are for reference only.
  • These diagrams are one version of many possible variations. We cannot be held responsible for errors
  • It is important that you call to us, to verify the parts you need are indeed what is listed.
  • Parts returned due to diagram variations will be subject to the normal restocking fees listed in our Terms and Conditions.



R.H. Runway Assembly S120114 L.H. Runway Assembly (includes cylinder, cables and sheaves) S110034 Whiz-Lock Bolt 40279 Turning Radius Gauge Ass'y FA5153 Turntable Guide Bar FA5153-1 Whiz-Lock Bolt 42073 Anchor Bolt FC5228 Rear Slip Plate Kit FC5249 Wheel Stop (SMO) FC342 Wheel Stop (ARO) FC134-13 Ramp Chock Assembly S110016 Cotter Pin 41202 Cotter Pin 41202 Push Nut Fastener FC5179-4 Push Nut Fastener FC5179-4 Hinge Pin FC134-99 Hinge Pin FC134-99 Ramp Chock Weld S120072 Changes to S110302BL Ramp Chock Slide FC134-33 Bolt 40050 Whiz-Lock Nut 40633 Front Latch Bar S120030 Triangular Wheel Chock FC320 Rolling Jack SB300001 Hydraulic Cylinder S130002 Cable Pull Bar S120075 Cable Retainer S120068 Hex Nut 40771 Hex Jam Nut 40773 Right Front Yoke Weldment S120091 Right Front Yoke Ass'y (Including Latches) S110048 Rear Yoke Weldment S120095 Rear Yoke Ass'y (Including Latches) S110023 Left Front Yoke Weldment S120089 Left Front Yoke Assembly (Including Latches) S110047 Power Unit Single Phase P1002 Change to P3350 Hex Nut 40765 Hex Jam Nut 40766 Flat Washer 41073 Rear Latch Bar S120028 Hex Jam Nut 40759 Hex Jam Nut 40759 Hex Nut 40760 Hex Nut 40760 Rear Column S120032 Power Unit Column S120033 Front Column S120036 Anchor Bolt FJ7380 Bolt 40115 USS Flat Washer Plated 40782 Nut 40642 Elbow P1028-4 Adapter Plate FA7132-2 Control Box 230V FA7133 Changes to FA7163 8mm Bolt 2 Req'd Pan Head Self-Tapping Screw 4 Req'd Stainless Steel Radius Gauge Rebuild Kit FA5153-2 Carbon Steel Radius Gauge Rebuild Kit FA5157-1 Slip Plate Weldment FC5190-16 Changes to FC5249 Ball Retainer Assembly FC5190-31 Ball FC5130-7 Lock Pin Assembly FC5283 SAE Washer 41073 Nylon Insert Jam Nut 40658 Bolt 40067 Airline Tubing FA2230-2 Airline Tubing FA2230-2 Airline Tubing FA2230-2 Union Tee FC5225-46 Valve FA3134-12 Plug FA2230-16 Union Tee FA2242-1 Tubing FA2230-2 Nameplate NP280 Control Ass'y T140073 Filter/ Muffler T14075 Tubing FA2230-15 Female Connector FA334-13 Control Bracket FA3217 Changes to S120457BK Clevis Pin FC5346-1 Cotter Pin 41247 Grommet S130015 Hose S130012 Recoil Hose FC147-14 Male Elbow FC147-7 Female Bulkhead FC147-1 Runway Tubing FC147-6 Tubing FC5313-2 Male Run Tee FC147-3 Male Branch Tee FC147-5 Left Front Cable S130030 Right Front Cable S130031 Right Rear Cable S130019 Left Rear Cable S130018 Sheave FC5804-2 Sheave FC5804-2 Sheave FC5804-2 Bearing FC5843-3 Bearing FC5843-3 Bolt 40401 Bolt 40401 Bolt 40401 Bolt 40401 Sheave Pin FC555-1 Sheave Pin FC555-1 Sheave Pin FC555-1 Sheave Pin FC555-1 Sheave Spacer S130161 Sheave Spacer S130161 Sheave Spacer S130161 Bolt 40252 Standard Sheave Pin FC5224-21 Sheave FC5804-2 Plastic Spacer FC5927-10 Bolt 40067 Plain Washer 40780 Cotter Pin 41201 Latch Shaft FC5901-7 Washer FC5301-98 Hairpin Cotter Pin 41901 Hairpin Cotter Pin 41901 Clevis Pin FA2230-12 Latch FC5706-10 Spacer FC5706-9 Snap Ring 41410 Slack Cable Roller FC553-21 Kicker S120103 Extension Spring FC522-25 Clevis Pin S130051 Air Cylinder 1-port S130061 Elbow FC5224-39 Clevis FC5706-7 Hex Nut 40622 Hex Nut 40622 Guard S130014 Tube Cap FC248 Spring Clip FC7115 Bolt 40252 Bolt 40252 Standard Sheave Pin FC5224-21 Sheave FC5804-2 Plastic Spacer FC5927-10 Slider FC5706-16 Bolt 40067 Guard FC5802-18 Plain Washer 40780 Cotter Pin 41201 Latch Shaft FC5901-7 Washer FC5301-98 Changes to 41387 Hairpin Cotter Pin 41901 Clevis Pin FA2230-12 Latch FC5706-10 Spacer FC5706-9 Snap Ring 41410 Slack Cable Roller FC553-21 Kicker S120103 Extension Spring FC522-25 Clevis Pin S130051 Flat Washer 40782 1-Port Air Cylinder S130061 Elbow FC5224-39 Clevis FC5706-7 Hex Nut 40622 Hex Nut 40622 Hairpin Cotter Pin 41901 Bolt 40340 Flat Washer 40980 Roller Assembly FC5905 Wheel Cover FC5905-5 Wheel Bearing FC5905-3 Slider FC5905-4 Wheel Spacer FC5905-9 Front Yoke Left S120089 Front Yoke Right S120091 Slider FC5905-8 Slider FC5905-8
