Rotary SPO9RA Parts Diagram

Diagrams are for reference only.

These diagrams are one version of many possible variations. We cannot be held responsible for errors.

It is important that you call to us, to verify the parts you need are indeed what is listed.

Parts returned due to diagram variations will be subject to the normal restocking fees listed in our Terms and Conditions.



L.H. Column Weldment N75 R.H. Column Weldment N76 Column Extension N45 Carriage Yoke Weldment N86 Outer Arm FJ7772-1 Outer Arm FJ7772-1 Hydraulic Cylinder FJ7664 Power Unit P702 Power Unit Hose FJ837 Bolt, Ext Tooth LW&Nut  40224 Inner Arm N210 Grade 8 Bolt 40155 3/4" Internal Tooth Lockwasher 40843 Inner Arm FJ7416-2 Adapter Pad FJ7735-3 Threaded Insert FJ7866-1 Rectangular Adapter Weldment FJ7859 Roll Pin 14451 Bleeder Screw ( specify manufacturer 2 req'd Carriage Bumper FJ7391-2 Changes to 95016 Arm Pin FJ7838 Approach Bumper FJ7391-1 Changes to 95016 Hex Lock Nut 40703 Cotter Pin 41250 Klipring 41411 Klipring 41411 Sheave FJ7116-1 Changes to N377 Sheave FJ7116-1 Changes to N377 Wheel Spotting Dish Kit FF729 Actuator Pin Handle FJ7985-1 Actuator Pin FJ7656-1 Retaining Ring FJ7646-2 Changes to FJ7646-1 Arm Restraint Spring FJ7656-2 120T Gear Block FJ7749 Spring Pin 14427 Sheave Cover N119-1 Bolt 40063 Bolts and Washers Gear Bolts 40200 Spring Washers 40818 Changes to 40815 Restraint Gear FJ7750 Slider Block FJ7360 Concreate Anchor FJ7380 Thick Mach. Bushing 41388 Bolt 40109 Changes to 911481 Insert Lock Nut 41423 Cotter Pin 41200 Limit Switch Assembly FJ7613 Changes to N413 Switch Bar Assembly FJ7613-2 R.H. Latch Sheave Bracket Assy. FJ7767 Changes to GP1011 R.H. Overhead Weldment N44-1 Bolt 40134 Flat Washer 40820 Overhead Hose FJ839 Changes to N3103 Equalizer Cable Assembly FJ7450 L.H. Overhead Weldment N43-1 Changes to N444BL Locking Latch Cable Assembly FJ7594-1 Changes to FJ7595-1 Bolt 40144 Bolt 40144 Bolt 40144 Flanged Locknut 40664 Sheave Shaft FJ7444-8 Bracket FJ7613-1 L.H. Latch Sheave Bracket Assy. FJ7766 Changes to GP1011 Locking Latch Sheave FJ7322 Truarc Klip 41410 Overhead Hose Clip FJ7206 Bolt 40033 Branch Tee FJ7668 Column Hose Clip FJ7499 Flanged Bolt 40122 Flanged Locknut 40641 Flanged Locknut 40641 Spacer FJ7871 3 Phase Limit Switch FJ7979 Changes to N414 Single Phase Limit Switch P467-2 Three Phase Limit Switch FJ7979-1 Limt Switch Bracket Cover FJ7979-2 External Tooth Lockwasher 40779 External Tooth Lockwasher 40845 External Tooth Lockwasher 40845 Zinc Hex Nut 40627 Changes to 40625 Arm Restraint Kit FJ7888 Changes to N2205 Straight Adapter FJ7352-3 Control Side Cover FJ7452 Locking Latch Dog FJ7382-7 Control Plate FJ7594-2 Spring FJ7382-2 Changes to FJ7382-3 Spring FJ7382-9 Latch Shaft FJ7382-3 Locking Latch Sheave FJ7322 Handle FJ7382-18 Ball Handle FC134-91 Truarc Klipring 41411 Truarc Klipring 41411 Truarc Klipring 41410 Mach. Bushing 41388 Slotted Screw 40227 Hex Jam Nut 40658 Shoulder Bolt 40220 Flanged Locknut 41423 Latch Cable FJ7594-1 Changes to FJ7595-1 Latch Cover FJ7451 Locking Latch Dog FJ7382-7 Control Plate FJ7382-5 Changes to FJ7594-2 Spring FJ7382-2 Changes to FJ7382-3 Spring FJ7382-3 Latch Shaft FJ7382-3 Locking Latch Sheave FJ7322 Soulder Bolt 40220 Truarc Klipring 41411 Truarc Klipring 41410 Mach. Bushing 41388 Slotted Screw 40227 Flanged Locknut 41423 Latch Cable FJ7504-1 Latch Cable Clamp KS-15 Changes to N63-1 Truarc Klipring 41411
