Rotary Model R146i Tire Changer Parts

This diagram can change at any time without notice, and is provided as a convenience for reference only, and should not be used to determine compatability. Please call or email us for confirmation.

diagram missing

Swing Arm All Units Except 3-Phase
Item	Part #	Description
1	VS14040107	Pin for arm
2	VS140401180	Arm adjustment
3	VS903075	Handwheel V6L
4	VS730092730	Assembling tool
5	VS903078	Pressure knob
6	VS140401170	Tie rod
7	VS730016890	Beam closing
8	VS413159	Trip plug
9	VS950001220	Spring
10	VS140320310	Washer
11	VS140710160	Vertical shaft handgrip
12	VS238012	25 elastic washer
13	VS730020250	Screw for neck
14	VS950001641	Spring
15	VS730020140	Lever for cam
16	VS730016880	Neck for hexagon
17	VS140315721	40 hexagon pad
18	VS730013490	Vertical hex nut
19	VS227023	M24x1,5 low nut
20	VS224011	M10 middle hexagonal nut
21	VS999913250	Head use plate
22	VS238007	10,5 elastic washer
23	VS228012	M10 self-locking nut
24	VS236007	Fe 10,5x21x2 washer
25	VS203108	TE M10x55 screw
26	VS243017	External seeger 35
27	VS206186	TCEI M12x25 screw
28	VS140440380	Tower clamping washer
29	VS140440390	Ball washer
30	VS203072	TE M12x30 screw
31	VS790011540	Spacer for hexagon
32	VS251105	Threaded insert
33	VS237566	Thickness washer
34	VS730013501	Column unit
35	VS730020150	Horizontal arm

3-phase

diagram missing

Swing Arm 3-Phase Units Only
Item	Part #	Description
1	VS730020960	Adjustment
2	VSB1202700	M-M1” nipple union
3	VS309095	Blow valve
4	VS237566	Thickness washer
5	VS14040107	Pin for arm
6	VS238012	25 elastic washer
7	VS227023	M24x1,5 low nut
8	VS903075	Handwheel V6L
9	VS950001641	Spring
10	VS730013490	Vertical hex nut
11	VS140320310	Washer
12	VS140710160	Vertical shaft handgrip
13	VS206186	TCEI M12x25 screw
14	VS730020140	Lever for cam
15	VS243017	External seeger 35
16	VS319012	Clamp
17	VS730092730	Assembling tool
18	VS903078	Pressure knob
19	VS730016880	Neck for hexagon
20	VS950001220	Spring
21	VS238007	10,5 elastic washer
22	VS224011	M10 middle hexagonal nut
23	VS140401170	Tie rod
24	VS228012	M10 self-locking nut
25	VS730016890	Beam closing
26	VS730020250	Screw for neck
27	VS413159	Trip plug
28	VS790011540	Spacer for hexagon
29	VS140315721	40 hexagon pad
30	VS140440380	Tower clamping washer
31	VS140440390	Ball washer
32	VS203072	TE M12x30 screw
33	VS236007	Fe 10,5x21x2 washer
34	VS203108	TE M10x55 screw
35	VS203193	TE M10x30 screw
36	VS325031	Rotary union
37	VS730016760	Y union
38	VS312156	1/4" nipples
39	VS251105	Threaded insert
40	VS318011	Screened pipe L= 700
41	VS311002	1/4M plug
42	VS325107	L rotary union
43	VS730020150	Horizontal arm
44	VS730018032	Welded rod

diagram missing

Rotary R146i Bead Breaker Group
Item	Part #	Description
1	VS730090511	Bead breaking cylinder
2	VS140920041	Cylinder bead-breaker barrel
3	VS140920380	D.54x18x4 washer
4	VS228020	18x1,5 selflocking nut
5	VS630036	Self-lubricating bushing
6	VS140926220	Gasket washer
7	VS140920550	Rear flange
8	VS140920062	M8 tie rod
9	VS730012781	D.25 rod
10	VS140920541	Front flange for rod
11	VS325107	L rotary union
12	VS140912061	Plate
13	VS299156	Seeger for hole
14	VSGU4740	Cylinder gasket kit
15	VS140920361	Cylinder fulcrum pin
16	VS140390731	Bead breaker arm assembly
17	VS140925901	Screw for bead-breaker arm
18	VS253017	Belleville washer
19	VS228006	M12 self-locking nut
20	VSB4004402	Arm
21	VSB4064201	Vane
22	VS903090	D. 40 ball knob
23	VS140320430	Arm fulcrum pin
24	VS730012100	Cam
25	VS730018740	Arm fulcrum
26	VS401013	O-ring
27	VS243022	External seeger
28	VS950020060	Arm return spring
29	VS730013650	Rubber spacer
30	VS730012090	Thrust pin
31	VS237525	Thickness washer
32	VS243013	External seeger 25
33	VS238004	6,4 elastic washer
34	VS206012	TCEI M6x10 screw
35	VS236006	8,4 flat washer
36	VS238006	8,4 elastic washer
37	VS222009	M8 high nut
38	VS408425	Scraper
39	VS401196	O-ring 183,74x3,53
40	VS220063	TCB M4,2x13 screw
41	VS140920140	Bead-breaker gasket
42	VS403123	Gasket
43	VS237069	Flat washer
44	VS269201	M6X10 TE self-drilling screw
45	VS237011	ø6x18 flat washer
46	VS210040	STEI M8x30 screw
47	VS206352	TCEI M8x100 screw
48	VS228302	M8 biblock nut

diagram missing

Rotary R146i Bead Breaker Group - Three Phase
Item	Part #	Description
1	VS730091161	Cylinder
2	VS730013450	Barrel
3	VS140920380	D.54x18x4 washer
4	VS228020	18x1,5 selflocking nut
5	VS630036	Self-lubricating bushing
6	VS140926220	Gasket washer
7	VS140920550	Rear flange
8	VS730013460	Tie rod
9	VS730013281	Rod
10	VS140920541	Front flange for rod
11	VS325107	L rotary union
12	VS140912061	Plate
13	VS299156	Seeger for hole
14	VSGU4740	Cylinder gasket kit
15	VS140920361	Cylinder fulcrum pin
16	VS140891480	Bead-breaker arm insert
17	VS140925901	Screw for bead-breaker arm
18	VS253017	Belleville washer
19	VS237069	Flat washer
20	VS228006	M12 self-locking nut
21	VS730011591	Bead breaker arm
22	VSB4064201	Vane
23	VS140320430	Arm fulcrum pin
24	VS730019860	Cam
25	VSB903090	Knob
26	VS401013	O-ring
27	VS950020060	Arm return spring
28	VS730012090	Thrust pin
29	VS730013650	Rubber spacer
30	VS237525	Thickness washer
31	VS243013	External seeger 25
32	VS238004	6,4 elastic washer
33	VS206012	TCEI M6x10 screw
34	VS730019810	Fulcrum pin
35	VS243022	External seeger
36	VS401196	O-ring 183,74x3,53
37	VS236006	8,4 flat washer
38	VS238006	8,4 elastic washer
39	VS222009	M8 high nut
40	VS408425	Scraper
41	VS403123	Gasket
42	VS140920140	Bead-breaker gasket
43	VS220063	TCB M4,2x13 screw
44	VS269201	M6X10 TE self-drilling screw
45	VS237011	ø6x18 flat washer
46	VS206352	TCEI M8x100 screw
47	VS228302	M8 biblock nut
48	VS210040	STEI M8x30 screw

diagram missing

Frame unit for Rotary R146i - All Units Except 3-Phase
Item	Part #	Description
1	VS730023910	Frame
2	VS599074	Cable press
3	VS251116	M8 threaded insert
4	VS203223	TE M12x40 screw
5	VS251107	M6 threaded insert
6	VS224015	M12 middle hexagonal nut
7	VS228250	M6 crated nut
8	VS730018871	Lateral pad
9	VS599418	Rubber-made fairlead
10	VS236006	8,4 flat washer
11	VS271038	TBEI M8X25 screw
12	VS251104	Threaded assembly

diagram missing

Frame unit for Rotary R146i 3-Phase
Item	Part #	Description
1	VS730022751	Frame
2	VS599074	Cable press
3	VS251116	M8 threaded insert
4	VS203223	TE M12x40 screw
5	VS251107	M6 threaded insert
6	VS224015	M12 middle hexagonal nut
7	VS228250	M6 crated nut
8	VS730018871	Lateral pad
9	VS599418	Rubber-made fairlead
10	VS236006	8,4 flat washer
11	VS271038	TBEI M8X25 screw
12	VS251104	Threaded assembly

diagram missing

Side Casing unit for Rotary R146i Except 3-Phase
Item	Part #	Description
1	VS730023570	Lateral casing
2	VS271021	TBEI M6x20 screw

diagram missing

Side Casing unit for Rotary R146i 3-Phase
Item	Part #	Description
1	VS730023961	Lateral casing
2	VSB1137000	Pedal black guard

diagram missing

Coupler unit for Rotary R140i & R146i V1
Item	Part #	Description
1	VSB7093000	2,62 x 64,77 O-ring

diagram missing

Coupler unit for Rotary R140i & R146i V2
Item	Part #	Description
1	VSB7093000	2,62 x 64,77 O-ring
2	VSB7092000	OR gasket

diagram missing

Turntable unit for Rotary R140i & R146i 18"
Item	Part #	Description
1	VS140815172	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140890013	Complete piston
5	VS317022	Rilsan pipe 8x6
6	VS140841601	U bracket
7	VS243006	Ring 14
8	VS140815600	Slide guide block
9	VS243026	Seeger Ø 75
10	VS140815412	Synchronizer
11	VS140815860	Little pipe
12	VS140815322	Slide guide
13	VS140815243	10”-18” mandrel assembly
14	VS140815053	Slide
15	VS140815044	Chuck jaw
16	VS235021	Elastic pin
17	VS140815403	Finger protection device
18	VS235052	Elastic pin
19	VS730023620	Locking washer
20	VS237076	Washer
21	VS140815810	Block
22	VS140815800	U bracket block
23	VS140815141	Bushing
24	VS299133	Seeger
25	VS140301252	Rear bottom
26	VS256256	TE M16x40 screw
27	VS236008	D.15 washer
28	VS203193	TE M10x30 screw
29	VS258258	TCEI M12x65 screw
30	VS140301241	Front bottom
31	VS228100	M6 self-locking nut
32	VS140815010	D.20 rod
33	VS140815162	Barrel
34	VS227015	M12 low nut
35	VS236011	13 flat washer
36	VS730023440	Point for jaw
37	VS730023630	Cap
A	VSGU3080	Gaskets kit

diagram missing

Turntable unit for Rotary R140i & R146i 20"
Item	Part #	Description
1	VS140815032	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140890023	10” - 20” cylinder
5	VS236011	13 flat washer
6	VS140841601	U bracket
7	VS243006	Ring 14
8	VS140815600	Slide guide block
9	VS243026	Seeger Ø 75
10	VS140815412	Synchronizer
11	VS730017970	Little pipe
12	VS140815322	Slide guide
13	VS140815981	10”-20” round mandrel assembly
14	VS730019880	Jaw support
15	VS140815044	Chuck jaw
16	VS256256	TE M16x40 screw
17	VS140815403	Finger protection device
18	VS235052	Elastic pin
19	VS730023620	Locking washer
20	VS236008	D.15 washer
21	VS203193	TE M10x30 screw
22	VS140815141	Bushing
23	VS299133	Seeger
24	VS237076	Washer
25	VS258216	TCEI M12x100 screw
26	VS238011	13 elastic washer
27	VS140301241	Front bottom
28	VS140301252	Rear bottom
29	VS140815010	D.20 rod
30	VS140815022	D.70 barrel
31	VS227015	M12 low nut
32	VS228100	M6 self-locking nut
33	VS730023440	Point for jaw
34	VS730023630	Cap
A	VSGU4870	Cylinder gasket kit D.70

diagram missing

Turntable unit for Rotary R140i & R146i 22"
Item	Part #	Description
1	VS140816501	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140891630	Complete piston
5	VS256256	TE M16x40 screw
6	VS140841601	U bracket
7	VS243006	Ring 14
8	VS140815600	Slide guide block
9	VS243026	Seeger Ø 75
10	VS140816430	Synchronizer
11	VS730017970	Little pipe
12	VS140815322	Slide guide
13	VS730019231	11”-22” mandrel assembly
14	VS730019880	Jaw support
15	VS140815044	Chuck jaw
16	VS258216	TCEI M12x100 screw
17	VS140816442	Finger protection device
18	VS271950	Screw
19	VS730023620	Locking washer
20	VS237076	Washer
21	VS236011	13 flat washer
22	VS236008	D.15 washer
23	VS140815141	Bushing
24	VS203193	TE M10x30 screw
25	VS140816780	Thickness
26	VS140816840	Spacer
27	VS299133	Seeger
28	VS238011	13 elastic washer
29	VS140301241	Front bottom
30	VS140301252	Rear bottom
31	VS228100	M6 self-locking nut
32	VS140816510	D.20 rod
33	VS140816491	D.70 barrel
34	VS227015	M12 low nut
35	VS317022	8x6 black Elastolan pipe L=2300
36	VS730023630	Cap
A	VSGU4870	Cylinder gasket kit D.70

diagram missing

Turntable unit for Rotary R140i & R146i 26"
Item	Part #	Description
1	VS140816560	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140891680	Complete piston
5	VS730019290	Spacer
6	VS730019180	U bracket assembly
7	VS243006	Ring 14
8	VS730019310	Bushing
9	VS243026	Seeger Ø 75
10	VS730092660	26 synchronizer
11	VS140816230	Little pipe
12	VS140815322	Slide guide
13	VS730019211	10”-26” mandrel assembly
14	VS730020910	Slide
15	VS140816221	Chuck jaw
16	VS235021	Elastic pin
17	VS140816362	Finger protection device
18	VS271950	Screw
19	VS730023620	Locking washer
20	VS236011	13 flat washer
21	VS140816371	Block
22	VS140816311	U bracket block
23	VS256069	TE M12x16 screw
24	VS236008	D.15 washer
25	VS730023630	Cap
26	VS140816151	Slide block
27	VS950001900	Spring
28	VS140816140	Pin
29	VS299051	D.7 stopper ring
30	VS256256	TE M16x40 screw
31	VS203193	TE M10x30 screw
32	VS140816840	Spacer
33	VS227015	M12 low nut
34	VS258258	TCEI M12x65 screw
35	VS237547	75x95x1 washer
36	VS299081	Washer
37	VS140301241	Front bottom
38	VS140301251	Rear bottom
39	VS140816550	Barrel
40	VS140815010	D.20 rod
41	VS228100	M6 self-locking nut
42	VS317022	8x6 black Elastolan pipe L=2500
43	VS730023440	Point for jaw
A	VSGU4870	Cylinder gasket kit D.70

diagram missing

Turntable unit for Rotary R140i & R146i 20" GT
Item	Part #	Description
1	VS140815032	Tie rod
2	VS325110	Union
3	VS325159	L union
4	VS140890023	10" - 20" cylinder
5	VS258216	TCEI M12x100 screw
6	VS140841601	U bracket
7	VS243006	External seeger 14
8	VS140815600	Slide guide block
9	VS243026	Seeger Ø 75
10	VS140815412	Synchronizer
11	VS730017970	Small pipe
12	VS140815322	Slide guide
13	VS140815981	10”-20” round mandrel assembly
14	VS730017941	Chuck jaw
15	VS140815044	Chuck jaw
16	VS256256	TE M16x40 screw
17	VS140815403	Finger protection device
18	VS235052	Elastic pin
19	VS730023620	Locking washer
20	VS237076	Washer
21	VS236011	13 flat washer
22	VS236008	D.15 washer
23	VS140815141	Bushing
24	VS203193	TE M10x30 screw
25	VS730023630	Cap
26	VS730023440	Point for jaw
27	VS299133	Seeger
28	VS238011	13 elastic washer
29	VS140301241	Front bottom
30	VS140301252	Rear bottom
31	VS228100	M6 self-locking nut
32	VS140815010	D.20 rod
33	VS140815022	D.70 barrel
34	VS227015	M12 low nut
35	VS317010	10x8 black rilsan pipe L=700
36	VS317021	10x8 black elastolan pipe
37	VS317022	8x6 black Elastolan pipe L=2200
38	VS325107	L rotary union
A	VSGU4870	Cylinder gasket kit D.70

diagram missing

Turntable unit for Rotary R140i & R146i 22" GT
Item	Part #	Description
1	VS140816501	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140891630	Complete piston
5	VS236008	D.15 washer
6	VS140841601	U bracket
7	VS243006	Ring 14
8	VS140815600	Slide guide block
9	VS243026	Seeger Ø 75
10	VS140816430	Synchronizer
11	VS730017970	Little pipe
12	VS140815322	Slide guide
13	VS730019231	11”-22” mandrel assembly
14	VS730017941	Chuck jaw
15	VS140815044	Chuck jaw
16	VS203193	TE M10x30 screw
17	VS140816442	Finger protection device
18	VS271950	Screw
19	VS730023630	Cap
20	VS237076	Washer
21	VS256256	TE M16x40 screw
22	VS258216	TCEI M12x100 screw
23	VS599095	Clamp
24	VS238011	13 elastic washer
25	VS140815141	Bushing
26	VS299133	Seeger
27	VS325107	L rotary union
28	VS236011	13 flat washer
29	VS140816780	Thickness
30	VS140816840	Spacer
31	VS140301241	Front bottom
32	VS140816491	D.70 barrel
33	VS227015	M12 low nut
34	VS140816510	D.20 rod
35	VS140301252	Rear bottom
36	VS228100	M6 self-locking nut
37	VS317010	10x8 black rilsan pipe L=700
38	VS317021	10x8 black elastolan pipe
39	VS317022	8x6 black Elastolan pipe L=2300
40	VS730023620	Locking washer
41	VS730023440	Point for jaw
A	VSGU4870	Cylinder gasket kit D.70

diagram missing

Turntable unit for Rotary R140i & R146i 26" GT
Item	Part #	Description
1	VS140816560	Tie rod
2	VS325110	Union
3	VS325159	Union
4	VS140891680	Complete piston
5	VS317022	8x6 black Elastolan pipe L=2500
6	VS730019180	U bolt assembly
7	VS243006	External seeger 14
8	VS730019190	Bushing
9	VS243026	Seeger Ø 75
10	VS730092660	26 synchronizer
11	VS140816230	Small pipe
12	VS140815322	Slide guide
13	VS730019211	10"-26" mandrel assembly
14	VS730020900	Slide
15	VS140816221	Chuck jaw
16	VS235021	Elastic pin
17	VS140816362	Finger protection device
18	VS271950	Screw
19	VS730023620	Locking washer
20	VS258258	TCEI M12x65 screw
21	VS140816371	Block
22	VS140816311	U bracket block
23	VS140816140	Pin
24	VS299051	D.7 stopper ring
25	VS730019310	Bushing
26	VS140816151	Slide block
27	VS950001900	Spring
28	VS140816840	Spacer
29	VS203193	TE M10x30 screw
30	VS730019290	Spacer
31	VS312052	1/4" extension
32	VS325107	L rotary union
33	VS317010	10x8 black rilsan pipe L=700
34	VS317021	10x8 black elastolan pipe
35	VS237547	75x95x1 washer
36	VSGU4870	Cylinder gasket kit D.70
37	VS401174	OR
38	VS403108	Gasket
39	VS321005	Complete piston
40	VS140816550	D.70 barrel
41	VS140815010	D.20 rod
42	VS227015	M12 low nut
43	VS140301241	Front bottom
44	VS140301251	Rear bottom
45	VS228100	M6 self-locking nut
46	VS236011	13 flat washer
47	VS256256	TE M16x40 screw
48	VS236008	D.15 washer
49	VS256069	TE M12x16 screw
50	VS299081	Washer
51	VS730023440	Point for jaw
52	VS730023630	Cap

Gearbox Transmission unit for Rotary R146i With Inverter
Item	Part #	Description
1	VS14030528	M10x210 tie rod for reducer
2	VS730023650	Threaded bar M10x180
3	VS140833340	Reducer support
4	VS231003	6x6x25 wrench
5	VS231068	10x8x45 wrench
6	VS412103	Belt
6	VS412005 ○	A26 trapezoidal belt
7	VS730012420	D.132 pulley
7	VSB8463000	D.132 pulley
8	VS730022960	Motorinverter support plate
8	VS140305261	Motor plate
9	VS140305521	Reducer insert
10	VS730091013	Motor unit
10	VS900000301	220V 60Hz motor unit
11	VS730014030	Pulley
11	VS730015240	D.68-46 pulley
12	VS213378	STEI M5x6 screw
13	VS210148	STEI M5x6 screw
14	VS900071190	Gasket
15	VS900071180	Termination box cover
16	VS900003720	0,75 kW motor

diagram missing

Gearbox Transmission unit for Rotary R146i With 2 Speed
Item	Part #	Description
1	VS140305521	Reducer insert
2	VS231068	10x8x45 wrench
3	VS730012420	D.132 pulley
3	VSB8463000■	D.132 pulley
4	VS231003	6x6x25 wrench
5	VS237037	8x32x2,5 flat washer
6	VS239023	8,4 toothed washer
7	VS203035	TE M8x20 screw
8	VS140833340	Reducer support
9	VS226011	M10 low hexagonal nut
10	VS730023580	Motor support blade
11	VS900001871	Electric motor
11	VS900003960■	0,75kW electric motor
12	VS730020220	D.71 pulley
12	VS730015240■	D.68-46 pulley
13	VS14030532	M10x170 tie rod for reducer
14	VS213188	M6x12 STEI cup point screw
15	VS412081	Rubber washer
16	VS201042	TE M8x40 screw
17	VS228011	M8 self-locking nut
18	VS224011	M10 middle hexagonal nut
19	VS239041	10,5 toothed washer
20	VS238007	10,5 elastic washer
21	VS236007	Fe 10,5x21x2 washer
22	VS201177	TE M10x60 screw
23	VS210406	M6x6 STEI flat screw
24	VS203058	TE M10x25 screw
25	VS237072	D.8,4x22x2,5 washer
26	VS203066	TE M10x50 screw
27	VS412103	Belt
27	VS412091■	Trapezoidal belt
	■ Valid for 110V 60Hz 1Ph 2V 0,75 kW version

diagram missing

Gearbox and Motor unit for Rotary R146i With 1 Speed, 3-Phase
Item	Part #	Description
1	VS140305521	Reducer insert
2	VS231068	10x8x45 wrench
3	VSB8463000	Pulley
4	VS231003	6x6x25 wrench
5	VS237037	8x32x2,5 flat washer
6	VS239023	8,4 toothed washer
7	VS203035	TE M8x20 screw
8	VS140833340	Reducer support
9	VS226011	M10 low hexagonal nut
10	VS14030532	M10x170 tie rod for reducer
11	VS224011	M10 middle hexagonal nut
12	VS239041	10,5 toothed washer
13	VS238007	10,5 elastic washer
14	VS236007	Fe 10,5x21x2 washer
15	VS201177	TE M10x60 screw
16	VS228012	M10 self-locking nut
17	VS203058	TE M10x25 screw
18	VS730095100	1-speed three-phase motor unit
19	VS203066	TE M10x50 screw
20	VS412005	Trapezoidal belt
21	VS900003960	Electric motor
22	VS730015240	Pulley
23	VS140305261	Motor plate

diagram missing

Filter/Oiler Assembly unit for Rotary R146i, Non-Inverter Models
Item	Part #	Description
1	VS140300402	MTG filter
2	VS303015	M 1/4-7 rapid coupling
3	VS325118	Rotary union
4	VS325148	T middle union
5	VS399318	Filter
6	VS399320	Lubricator
7	VSB4191901	Filter support
8	VSB0223000	C grease holding ring
9	VS325151	Cap

diagram missing

Filter/Oiler Assembly unit for Rotary R146i, Inverter Models
Item	Part #	Description
1	VS140300472	MTG filter
2	VS303022	Rubber holder
3	VS325118	Rotary union
4	VS325148	T middle union
5	VS325203	T union
6	VS399318	Filter
7	VS399320	Lubricator
8	VSB4191901	Filter support
9	VSB0223000	C grease holding ring

diagram missing

Filter/Oiler Assembly unit for Rotary R146i, 3-Phase Models
Item	Part #	Description
1	VS203172	TE M8x16 screw
2	VS203160	TE M4x12 screw
3	VS272038	TE M8x25 screw
4	VS399319	Filter unit
5	VSB4191901	Filter support
6	VSB0223000	C grease holding ring
7	VS325118	Rotary union
8	VS325148	T middle union
9	VS325203	T union
10	VS303022	Rubber holder
11	VS730090312	Conditioning unit
12	VS399320	Lubricator filter unit

diagram missing

Inverter Assembly unit for Rotary R146i - Non-GT Models
Item	Part #	Description
1	VS730090955	Inverter
2	VS730024780	Inverter support plate
3	VS900071190	Gasket
4	VS999916011	Motoinverter plate
5	VS710265061	Inverter cable
6	VS730065021	Power cable
7	VS710565020	Inverter signal cable
