Rotary RTP10 Revolution 2-Post Lift 3-Stage RA Arms

Rotary Rotary-RTP10 Please Call for Lead Time

To order by telephone, please call +1 866.990.0911

$4,737.00

Four out of Five Stars

No reviews have been submitted for this product

Please Call for Lead Time



RTP10 Features:



  • Overhead padded switch bar to avoid vehicle damage from being
  • raised too high
  • 3-Stage front arm design enables you to position vehicle doors in front of or behind columns to avoid door damage
  • Top mounted pull design hydraulic cylinder. The piston rod is protected behind the carriage to prevent damage
  • Overhead cable equalization
  • Spring operated arm restraints, disengage at floor level
  • Single point lock release
  • Two full-stroke cylinders with overhead cable for equalization
  • Large rubber-padded swivel truck adapters with extra height extensions are standard.
  • ALI Certified


    Click here for information on ALI certifications



    Specifications RTP10
    Capacity 10,000 lbs.
    Rise 77"
    Overall Height 143-1/8"
    Overall Width 131" (optional 137")
    Drive Through Clearance 97" (optional 103")
    Overhead Switch Height 136-1/4"
    Front Arm Reach (Min/Max) 23" / 44-1/2"
    Rear Arm Reach (Min/Max) 38-7/8" / 58"
    Min. Adapter Height 3-5/8" / 10"
    Width Inside Columns 109-3/4" (optional 115-3/4")
    Voltage/Amps 208/230, 20 Amps
    Motor / Phase 2 HP / 2 HP / 10*
    Min. Ceiling Height 144"





Here is a picture of the arm and adapters



Kit details for: RTP10N300MBL

Part Number Part Description Quantity in Kit
TPB10-0001BL I10/RTP10 BASE KIT 1
IN20527 2POST DECAL INST INSTRUCTIONS 1
LP20504 REVOLUTION RTP10 SRS100 LIT PK 1
NP820 REVOLUTION NAMEPLATE (DECAL) 2
NP909 LIFT SERIAL # NAMEPLATE 1
14602 ALI/ETL - ALCTV/UL-201-CSA 1
NP865 ALI/WLSIA01 SAFETY INSTRUCTNS
